| SPECIFICATIONS |
|
| Signal system |
PAL |
| Image device |
1/3" IT CCD
(with complementary colour filter) |
| Number of effective pixels |
440,000 (752 H x 582 V) |
| Video Processing |
Built-in DSP (10-bits) |
| Pickup area |
4.8 mm (H) x 3.6 mm (V) |
| Sync system |
Internal, Line Lock (50Hz regions only) |
| Scanning system |
2:1 interlaced, 625 lines |
| Scanning frequency |
15.625kHz (H); 50Hz (V) |
| Video output |
Composite video signal: 1.0 V(p-p), 75 ohms |
| Video S/N |
50 dB (AGC OFF) |
| Horizontal resolution (typical) |
540 TV lines |
Minimum illumination (typical)
Colour mode:
B&W mode: |
0.7 lx (F1.2, AGC ON, video level 25 %)
1.5 lx (F1.2, AGC ON, video level 50 %)
0.48 lx (F1.2, AGC ON, video level 25 %)
1.0 lx (F1.2, AGC ON, video level 50 %) |
| Iris control |
Video iris/DC iris |
| White balance |
ATW/Manual |
| BLC |
ON/OFF |
| AES |
ON/OFF (1/50 to 1/100,000 sec.) |
| Lens mount |
C/CS |
| Power supply |
TK-C920E(A): AC 24 V (50/60 Hz), DC 12 V
TK-C921EG(A): AC 220 V to 240 V (50/60 Hz) |
| Power consumption |
TK-C920E(A): 380 mA
TK-C921EG(A): 57 mA |
| Operating temperatures |
-10°C to 50°C
0°C to 40°C (Recommended ) |
| Weight |
TK-C920E(A): 370 g
TK-C921EG(A): 713 g |
