| SPECIFICATIONS |
|
| GENERAL |
|
| Power supply |
AC 120 V, 50/60 Hz |
| Power consumption |
Approx. 19 W (6W in Standby mode) |
| Dimensions (W x H x D) |
14-3/16 x 4-9/16 x 12-7/8 inches
360 x 115 x 327 mm |
| Weight |
5.5 kg (12.1 Ibs.) |
| Temperature |
Operating +5°C to +40°C (41°F to 104°F)
Storage -20°C to +60°C (-4°F to 140°F) |
| Tape speed |
33.35 mm/sec (2H mode) |
| Recording and playback time |
2H/6H/L12/L18/L24/24/48/72/120/168/240/480/960 with T-120 cassette tape |
| VIDEO |
|
| Signal system |
NTSC-type color signal, EIA monochrome signal, 525 lines/60 fields |
| Recording system |
Luminance: FM recording
Chrominance: Down converted direct recording |
| Signal input |
1.0 V(p-p), 75 ohms, unbalanced |
| Signal output |
1.0 V(p-p), 75 ohms, unbalanced |
| Horizontal resolution |
300 lines or more (2H mode) |
| S/N ratio |
43 dB or more (2H mode) |
| AUDIO |
|
| Number of tracks |
1 |
| Line input |
-8 dBs, 50 kohms, unbalanced |
| Mic input |
-67 dB, 600 ohms, unbalanced |
| Line output |
-8 dBs, 1 kohm, unbalanced |
| Frequency response |
100 Hz to 10 kHz (2H mode) |
| S/N ratio |
40 dB or more (2H mode at 4% distortion level) |
| TIME/DATE GENERATOR |
|
| Display |
Month, day, year, hours, minutes, seconds, recording mode, alarm input data, power loss time |
| Character size |
16H |
| Memory backup |
Approx. five years |
| ALARM |
|
| Input |
Input-ground contact |
| Camera SW output |
Negative pulse output (approx. 5 ms) |
| ACCESSORIES |
|
| Provided accessory |
Power cable x 1 |
| OPTIONAL ACCESSORIES |
|
SA-K97U:
RM-G30U: |
RS-232C interface
Remote control unit |
