| SPECIFICATIONS |
|
| GENERAL |
|
| Power supply |
AC 120 V, 50/60 Hz |
| Power consumption |
Approx. 16 W (4 W in Standby mode) |
| Dimensions (W x H x D) |
14-3/16 x 3-3/4 x 11-3/8 inches
360 x 94 x 288 mm |
| Weight |
5 kg (11.0 Ibs.) |
| Temperature |
Operating: +5°C to +40°C (41°F to 104°F)
Storage: -20°C to +60°C (-4°F to 140°F) |
| Tape speed |
11.12 mm/sec. (8H), 3.71 mm/sec. (24H), 2.22 mm/sec. (40H) |
| Recording and playback time |
8-hour Realtime
24, 40-hour mode
(High-Density: field recording/playback)
(with T-160 cassette) |
| VIDEO |
|
| Signal system |
NTSC-type color signal, 525 lines/60 fields |
| Recording system |
Luminance: FM recording
Chrominance: Down converted direct recording |
| Signal input |
0.5 to 2.0 V(p-p), 75 ohms, unbalanced (BNC) |
| Signal output |
1.0 V(p-p), 75 ohms, unbalanced (BNC) |
| Horizontal resolution |
Color mode: 230 lines or more (8-hour Realtime) |
| S/N ratio |
43 dB or more (8-hour Realtime) |
| AUDIO |
|
| Number of tracks |
1 (normal) |
| Line input |
-8 dBs, 50 kohms, unbalanced (RCA) |
| Mic input |
-67 dBs, 600 ohms, unbalanced |
| Line output |
-8 dBs, 1 kohm, unbalanced (RCA) |
| Frequency response |
100 Hz to 5 kHz (8-hour Realtime) |
| S/N ratio |
40 dB or more (8-hour Realtime) |
| TIME/DATE GENERATOR |
|
| Display |
Month, day, year, hours, minutes, seconds, recording mode |
| Display position |
4 positions |
| Character size |
16H |
| Power backup |
Approx. five years |
| INPUT/OUTPUT TERMINALS |
|
| Alarm input |
Input-ground contact |
| Camera SW output |
Negative pulse output (approx. 5 ms) |
| OPTIONAL ACCESSORIES |
|
SA-K97U:
RM-G30U: |
RS-232C interface
Remote control unit |
