FEATURES
- 168 hours of high-density recording
- 6-hour realtime recording
- Shuttle ring operation
- One-touch time search/alarm search function
- Alarm mode automatic selection during timer recording
- Key lock function
- Aluminum diecast mechanism for long-lasting reliability
- Easy to maintain with solderless drum
- Optional RS-232C interface
- Series recording
- FDP counter display/ hour meter (on screen)
- Alarm/sensor recording
- Timer recording
- Automatic recording check mode
- Field recording/playback
- Auto tape eject function
|
|
 |
| SPECIFICATIONS |
|
| GENERAL |
|
| Power supply |
AC 120 V, 50/60 Hz |
| Power consumption |
Approx. 16 W (5 W in Standby mode) |
| Dimensions (W x H x D) |
14-3/16 x 3-3/4 x 11-3/8 inches
360 x 94 x 288 mm |
| Weight |
5 kg (11.0 lbs.) |
| Temperature |
Operating: +5°C to +40°C (41°F to 104°F)
Storage: -20°C to +60°C (-4°F to 140°F) |
| Tape speed |
11.12 mm/sec., EP mode |
| Recording and playback time |
6 hours (EP mode)
(High-density mode: field recording)
6, L18, L30, 48, 72, 96, 120, 168, 240 hours
(with T-120 cassette)
8, L24, L40, 64, 96, 128, 160, 224, 320 hours
(with T-160 cassette) |
| VIDEO |
|
| Signal system |
NTSC-type color signal, 525 lines/60 fields |
| Recording system |
Luminance: FM recording
Chrominance: Down converted direct recording |
| Signal input |
0.5 to 2.0 V(p-p), 75 ohms, unbalanced (BNC) |
| Signal output |
1.0 V(p-p), 75 ohms, unbalanced (BNC) |
| Horizontal resolution |
Color mode: 230 lines or more (6H mode) |
| S/N ratio |
43 dB or more (6H mode) |
| AUDIO |
|
| Number of tracks |
1 (normal) |
| Line input |
-8 dBs, 50 kohms, unbalanced (RCA) |
| Mic input |
-67 dBs, 600 ohms, unbalanced |
| Line output |
-8 dBs, 1 kohm, unbalanced (RCA) |
| Frequency response |
100 Hz to 5 kHz (6H mode) |
| S/N ratio |
40 dB or more (6H mode) |
| TIME/DATE GENERATOR |
|
| Display |
Month, day, year, hours, minutes, seconds, recording mode |
| Display position |
4 positions |
| Character size |
16H |
| Power backup |
Approx. five years |
| ALARM |
|
| Input |
Input-ground contact |
| Camera SW |
Negative pulse output (approx. 5 ms) |
| OPTIONAL ACCESSORIES |
|
SA-K97U:
RM-G30U: |
RS-232C interface
Remote control unit |
|
|
