| SPECIFICATIONS |
|
| GENERAL |
|
| Power supply |
AC 120 V, 60 Hz |
| Power consumption |
20 W (2.5 W with power off) |
| Dimensions (W x H x D) |
15-3/4 x 3-3/4 x 11-3/16 inches
400 x 94 x 283 mm |
| weight |
3.4 kg (7.5 lbs.) |
| Temperature |
|
Operating:
Storage: |
5°C to 40°C (41°F to 104°F)
-20°C to 60°C (-4°F to 140°F) |
| Operating position |
Horizontal only |
| Format |
S-VHS/VHS NTSC standard |
| Maximum recording time |
|
SP:
EP: |
210 min. with ST-210 video cassette
630 min. with ST-210 video cassette |
| VIDEO/AUDIO |
|
| Signal system |
NTSC-type color signal and EIA monochrome signal, 525 lines/60 fields |
| Recording/Playback system |
DA-4 (Double Azimuth) head helical scan system |
| Signal-to-noise ratio |
45 dB |
| Horizontal resolution |
|
VHS:
S-VHS: |
230 lines
400 lines |
| Frequency range |
|
Normal audio:
Hi-Fi audio: |
70 Hz to 10,000 Hz
20 Hz to 20,000 Hz |
| Input/output |
RCA connectors (IN x 2, OUT x 1), S-video
connectors (IN x 2, OUT x 1) |
| TUNER |
|
| Tuning system |
Frequency-synthesized tuner |
| Channel coverage |
VHF: Channels 2 to 13
UHF: Channels 14 to 69
CATV: 113 Channels |
| RF output |
Channel 3 or 4 (switchable; press to Channel 3 when shipped), 75 ohms, unbalanced |
| TIMER |
|
| Clock reference |
Quartz |
| Program capacity |
1-year programmable timer/8 programs |
| Memory backup time |
Approx. 6 months, estimated figure based on supplied fresh battery; actual Performance may differ. |
| ACCESSORIES |
Infrared remote control unit
"AA" battery x 2
Lithium battery CR2025
S-video cable (4-pin)
RF cable (F-type)
Audio/video cable
BNC/RCA adapter x 2 |
