FEATURES
- Maximum 2 hard-disk drive capability with one hot-swapping removable disk
- Network capability via Ethernet connection
- Time-lapse and real-time recording
- Refresh rate up to 60 fps.
Select from the following: 60, 30, 20, 12, 5.5, 2.4, 1.22, 0.71, 1f/4S, 1f/6S, 1f/8S
- Four image recording quality levels: Best, High, Standard, and Basic
- Event/Timer/Alarm recording modes
- Quick search by time/alarm/event/recording list/ filter (thumbnail)
- Maintenance-free hard-disk recording with no heads to clean or tapes to degrade
- Plug & play replacement for time-lapse VCRs
- Compatible with popular multiplexers on the market
|
|
 |
| SPECIFICATIONS |
|
| Storage media |
80 GB HDD (can be increased up to 240 GB) |
| Max. number of HDD |
2 |
| Picture compression |
JPEG |
| Video format |
NTSC |
| Video input |
BNC x 1
BNC x 1 (for multiplexer In) |
| Video output |
BNC x 1
BNC x 1 (for multiplexer out) |
| Compression |
MJPEG |
| Resolution |
720 x 240
352 x 240 (60 fps) |
| Audio input |
RCA x 1 (Line) |
| Audio output |
RCA x 1 (Line), 16-bit, 8 kHz |
| Communication |
RS-232 x 1, RS-485 x 2 |
| LAN |
RJ45 x 1 (10-100 base TX) |
Alarm iIn/out
|
input x 1
output x 1 |
| Recording rate |
30 fps (60 fps for 352 x 240) |
| Image size |
Best: 48 KB
High: 32 KB
Standard: 2 1KB
Basic: 16 KB |
| Network protocol |
TCP/IP, DHCP, HTTP, SMTP, UDP, FTP, PPP |
| Power supply |
AC 120 V; 50/60 Hz
Output DC 12 V (AC Adapter) |
| Dimensions (W x H x D) |
220 x 89 x 320 mm |
| Weight |
3.9 kg |
|
